10T Automatic Pipe-up Growing Line With 2*2.2KW Motor For Vessel Welding
10T Automatic Pipe-up Growing Line With 2*2.2KW Motor For Vessel Welding
Quickly Details:
Type:Pipe-up Growing Line
Brand:Weld-Max
Condition:100% brand new
Model number:HGKS
Capacity:5Ton – 1000Ton
Consist: (1) Drive unit , (1) Idler unit , (1) Control box with hand panel
Voltage:110V-600V
Painting Color:Yellow & Blue /Yellow & Grey / Yellow & Black / Red&Black
Place of origin:Wuxi , China(Mainland)
Product Description:
Welding rotator is a kind of advanced welding equipment ,which is be researched and manufactured absorbing domestic international advanced equipment.The roller bed used the plate weld with more higher strength that can ensure used long time cab’t be transformation,also they make process technology used synchro so it’s will ensure drive and idler of roller center same.The electric control box with VFD adjust speed system to consists,main used contorl motor action to realize technology require of machine action,also control and protect the roller motor,mainly lower voltage elements used Schneider with more sare and reliable.
Application:
1Pressure vessels
2Pipe manufacturing industries
3Wind power fabrication
4Chemical & fuel storage tank fabrication
5Any heavy cylindrical job
Product Parameter:
|
Type |
Max loading (kg) |
Vessel diameter(mm) |
Dia. and width of the wheel(mm) |
Roller linear velocity(m/h) 6-60 |
Power of motor(kw) |
|
|
Rubber rollers |
Metal rollers |
|||||
|
HGK-5 |
5,000 |
Φ250-2300 |
Φ250×100 |
2×Φ240×20 |
2X0.37 |
|
|
HGK-10 |
10,000 |
Φ320-2800 |
Φ300×120 |
2×Φ290×25 |
2X0.55 |
|
|
HGK-20 |
20,000 |
Φ500-3500 |
Φ350×120 |
2×Φ340×30 |
2X0.75 |
|
|
HGK-40 |
40,000 |
Φ600-4200 |
Φ400×120 |
2×Φ390×40 |
2X1.5 |
|
|
HGK-60 |
60,000 |
Φ750-4800 |
Φ450×120 |
2×Φ440×50 |
2X2.2 |
|
|
HGK-80 |
80,000 |
Φ850-5000 |
Φ500×120 |
2×Φ490×60 |
2X3 |
|
|
HGK-100 |
100,000 |
Φ1000-5500 |
Φ500×120 |
2×Φ490×80 |
2X3 |
|
|
HGK-150 |
150,000 |
Φ1000-6000 |
/ |
Φ620×220 |
2X4 |
|
|
HGK-250 |
250,000 |
Φ1800-7500 |
/ |
Φ660×260 |
2X5.5 |
|
|
HGK-500 |
500,000 |
Φ1800-8000 |
/ |
Φ750×400 |
2X7.5 |
|
