Circular Seam Welding Manipulator (Submerged Arc Welding)

Short Description:

Quickly Details: Type: Welding Manipulator / Column and Boom Brand:Sanlian Heavy Industry Condition:100% brand new Model number:LH Size:LH-1010-LH-8080 Consist: (1) Column, (1) Boom , (1)Travel cart, (1) Control box with hand panel Voltage:110V-600V Painting Color:Yellow & Blue /Yellow & Grey / Yellow & Black / Red&Black Place of origin:Wuxi , China(Mainland) Application : 1. Pressure vessels welding 2. Pipe manufacturing industries 3. Wind power fabrication 4. Chemical & ...


  • FOB Price: Negotiable
  • Min.Order Quantity: 1set
  • Supply Ability: 30sets per Month
  • Port: Shanghai
  • Payment Terms: T/T or 100% LC at sight
  • Description and Parameters

    Brand Using

    Details Photo

    Packing and Shipment

    Product Tags

    Quickly Details:

    Type: Welding Manipulator / Column and Boom

    Brand:Sanlian Heavy Industry

    Condition:100% brand new

    Model number:LH

    Size:LH-1010-LH-8080

    Consist: (1) Column, (1) Boom , (1)Travel cart, (1) Control box with hand panel

    Voltage:110V-600V

    Painting Color:Yellow & Blue /Yellow & Grey / Yellow & Black / Red&Black

    Place of origin:Wuxi , China(Mainland)

    Application :

    1. Pressure vessels welding

    2. Pipe manufacturing industries

    3. Wind power fabrication

    4. Chemical & fuel storage tank fabrication

    5. Any heavy cylindrical welding job

    Product Description :

    The welding manipulator, also called column boom manipulator, we can provide you with three types of welding manipulators for our clients: fixed, fixed and rotating manipulator, moved manipulators. It is mainly used to offer firm support for high-precise welding, and can be also used for welding vessels, wind towers, pipe welding, and many others.

    This welding manipulator can reach both of the inside small internal diameters and the outside of big diameters in order to weld circumferential joints as well as longitudinal joints.

    Furthermore, we can attach more functions to this welding manipulator, such as tracing, monitoring, and solder recycling function. And we can also design and manufacture welding manipulators in accordance with specific demands of our clients.

    Features of welding manipulator:

    1.To make the positioning of the boom stable and smooth, the column is equipped with a brake motor.
    2.The guide holder has a safety pin, and the column has a row of security holes. The safety pin will enter into a security hole when the chain breaks down. In this way, serious accidents are successfully avoided.
    3.The guide holder connects the boom with the column, thus making the vertical adjustment and horizontal extension possible.
    4.The boom is also equipped with a cross electrical regulator, which can adjust the welding positon.
    5.A stepless speed regulating converter, with stable and reliable performance, is used to control the extension of the boom. And the converter has a failure testing mechanism, which will give an alarm when something wrong happens.
    6.This column boom manipulator adopts a total-sealing oil immersion lubricating mode to help keep off dust, slag, and many other impurities.

    Option items

    1. Welding seam tracker;
    2. Welding oscillator;
    3. Manned seat or flatform;
    4. Camera, monitor for welding process abservation;
    5. Flux recovery & convery machine;
    6. Lincoln welding power (DC-1000);
    7. Chinese welding power(MZ-1000 or MZ-1250);



    Technical Parameters

    Model Boom Column Traveling cart Power KW
      Vertical stroke (A)m Horizontal stroker (B)m Elevation speed m/min Traverse speed m/min Max load at extremity kg Total height (C)m Dimensions
    (D)×(E)×H m
    Rail c to c(F)mm
    LH1515 1.5 1.5 0.3 0.12~1.2 100 2.9 1.25×1.2×0.2 1052 0.91
    LH2020 2.0 2.0 0.3   100 3.4 1.25×1.2×0.2 1052 0.91
    LH3030 3.0 3.0 1.0   200 5.5 2.4×1.9×0.4 1600 2.75
    LH3040 3.0 4.0 1.0   200 5.5 2.4×1.9×0.4 1600 2.75
    LH4040 4.0 4.0 1.0   200 6.5 2.4×1.9×0.4 1600 2.75
    LH4050 4.0 5.0 1.0   200 6.5 2.4×1.9×0.4 1600 2.75
    LH5050 5.0 5.0 0.9   300 7.8 2.6×2.1×0.5 1798 3.5
    LH5060 5.0 6.0 0.9   300 7.8 2.6×2.1×0.5 1798 3.5
    LH6060 6.0 6.0 0.9   300 9.7 2.6×2.1×0.5 1798 3.5
