Elevating Welding Positioner

Short Description:

Quickly Details: Type:Elevating Welding Positioner Brand:Sanlian Heavy Industry Condition:100% brand new Model number:EHBJ Capacity:1000kg-200,000 kg Consist: (1) Main frame (1) Control box with hand panel and foot switch Voltage:110V-600V Painting Color:Yellow & Blue /Yellow & Grey / Yellow & Black / Red&Black Place of origin:Wuxi , China(Mainland) Application : 1. Pipe to pipe (or Elbow or Flange); 2. Welded Barrels 3. Storage tanks 4.  Industrial drums 5. Tank and drum fabr...


  • FOB Price: Negotiable
  • Min.Order Quantity: 1set
  • Supply Ability: 30sets per Month
  • Port: Shanghai
  • Payment Terms: T/T or 100% LC at sight
  • Description and Parameters

    Details Photos

    Brand Using

    Packing and Shipment

    Product Tags

    Quickly Details:

    Type:Elevating Welding Positioner

    Brand:Sanlian Heavy Industry

    Condition:100% brand new

    Model number:EHBJ

    Capacity:1000kg-200,000 kg

    Consist: (1) Main frame (1) Control box with hand panel and foot switch

    Voltage:110V-600V

    Painting Color:Yellow & Blue /Yellow & Grey / Yellow & Black / Red&Black

    Place of origin:Wuxi , China(Mainland)

    Application :

    1. Pipe to pipe (or Elbow or Flange);

    2. Welded Barrels

    3. Storage tanks

    4.  Industrial drums

    5. Tank and drum fabrication

    6. Cylindrical structure cutting of cylindrical job pipe elbow

    7. Framework of car, digger arm, loading machine, digger machine

    Product Description

    Elevating Welding positioner consists of turning and overturning mechanism of working table .Turning and overturning make the workpiece to reach a reasonable welding and fitting angle by the elevating of the working table,the turning of the working table is frequency conversion which can get a satisfactory welding speed.Because of the offset from center and gravity center ,To the longer and more offset from gravity center workpiece large model should be chosen.

    Technical Parameters

    Model

    Rated load Cap

     (tons)

    Power (kw)

    Max Gravity height

     (mm)

    Max
    centroid Eccentricity  (mm)

    Table

    Max Rotation Ф@ 90

    degree

    Tilt Angle (degree)

    Rotation

    Tilt

    Speed(rpm)

    Diameter (mm)

    Rotation
    (variable)

    Tilt (constant)

    EHBJ-10

    1

    1.1

    1.5

    250

    200

    0.05~05

    0.67

    1200

    2000

    0~120

    EHBJ-20

    2

    1.1

    1.5

    300

    200

    0.05~05

    0.23

    1400

    2100

    0~120

    EHBJ-30

    3

    1.5

    2.2

    300

    200

    0.05~05

    0.23

    1400

    2100

    0~120

    EHBJ-50

    5

    2.2

    3

    300

    200

    0.05~05

    0.14

    1500

    2500

    0~120

    EHBJ-80

    8

    2.2

    4

    400

    200

    0.02~0.2

    0.14

    2000

    3200

    0~120

    EHBJ-100

    10

    3

    5.5

    400

    200

    0.02~0.2

    0.14

    2000

    3200

    0~120

    EHBJ-150

    15

    3

    5.5

    450

    200

    0.015~0.15

    0.1

    2200

    3200

    0~120

    EHBJ-200

    20

    4

    7.5

    450

    200

    0.015~0.15

    0.1

    2300

    3200

    0~120

    Select the accessries you need

    1) Foot Panel

    2) Wireless Control Panel

    3) Three jaws self-clamp chuck
