20T Vertical Auto Head And Tail Stock With Pipe Flange Turning Table For Special Work
20T Vertical Auto Head And Tail Stock With Pipe Flange Turning Table For Special Work
Quickly Details:
Type: Head Tail Welding Positioner
Brand：Weld-max
Condition:100% brand new
Capacity:1000kg-200,000 kg
Consist: (1) Main fra me (1) Control box with hand panel
Voltage:110V-600V
Painting Color:Yellow & Blue /Yellow & Grey / Yellow & Black / Red&Black
Place of origin:Wuxi , China(Mainland)
Application:
1Pressure vessels.
2Pipe manufacturing industries
3Wind power fabrication
4Chemical & fuel storage tank fabrication
5Any heavy cylindrical job
Product Description:
The positioner can be supplied for interfacing with robot or welding manipulators,to realize the welding automation.At the same time we can design and customize various type of special positioner according to the technological requirement and different work piece given by the customer. Welding positioner series can divide into side tilting type , head to tail rotary type, head& tailstock lifting rotary type, head& tailstock tilting type, double rotary type positioner. The positioner can work with welding column& boom to realize the automatic special purpose welding center. As robot peripherals, it can also work with robot to realize automatic welding .
Product Parameter:
| Model |
Rated load Cap (tons) |
Power (kw) |
Max Gravity height (mm) |
Max centroid Eccentricity (mm) |
Table |
Max Rotation Ф@ 90 degree |
Tilt Angle (degree) | |||
| Rotation | Tilt | Speed(rpm) | Diameter (mm) | |||||||
| Rotation (variable) |
Tilt (constant) | |||||||||
| HBJS-10 | 1 | 1.1 | 1.5 | 250 | 200 | 0.05~05 | 0.67 | 1200 | 2000 | 0~120 |
| HBJS-20 | 2 | 1.1 | 1.5 | 300 | 200 | 0.05~05 | 0.23 | 1400 | 2100 | 0~120 |
| HBJS-30 | 3 | 1.5 | 2.2 | 300 | 200 | 0.05~05 | 0.23 | 1400 | 2100 | 0~120 |
| HBJS-50 | 5 | 2.2 | 3 | 300 | 200 | 0.05~05 | 0.14 | 1500 | 2500 | 0~120 |
| HBJS-80 | 8 | 2.2 | 4 | 400 | 200 | 0.02~0.2 | 0.14 | 2000 | 3200 | 0~120 |
| HBJS-100 | 10 | 3 | 5.5 | 400 | 200 | 0.02~0.2 | 0.14 | 2000 | 3200 | 0~120 |
| HBJS-150 | 15 | 3 | 5.5 | 450 | 200 | 0.015~0.15 | 0.1 | 2200 | 3200 | 0~120 |
| HBJS-200 | 20 | 4 | 7.5 | 450 | 200 | 0.015~0.15 | 0.1 | 2300 | 3200 | 0~120 |
